Highlights The AITech ProA/V Media Extender Mini adopts the newest in wireless A/V transmission technology to send audio and video signals throughout your home or office. Enjoy your favorite TV programs, DVD Movies, Music CD's MP3 Files, or listen to Stereo Hi-Fi in your home or office without any unnecessary cables! The ProA/V Media Extender Mini allows the user the flexibility to connect the transmitter to any composite A/V output device: PC, DVD player, CD player, VCR, camcorder, CMOS security Camera, TiVo Box, satellite receiver, cable TV box, projector, PC with composite video-out, AITech scan converter, or to any other device that outputs an RCA/Composite Audio/Video signal! Another outstanding feature of the ProA/V Media Extender Mini is its ability to use the remote control of the device it connects to. The built-in IR Extender wirelessly transmits the IR Signal from your VCR's, DVD Player's, or other device's hand held remote control, from the receiver side of the system back to your video source.

 Features

• Compatible with all TV's (Standard, HDTV, LCD and Plasma) that have an RCA/Composite input
• 2.4GHz wireless transmitter and receiver with 4 selectable channels
• Transfers video and audio wirelessly from DVD, VCR, STB, camcorders, CMOS cameras, PCs with composite video-out, projectors and more to your TV set
• Upgrades your existing wired AITech scan converter to wireless
• Remotely control your A/V source from another room with the built-in IR extender
• Built-in dipole antenna
• Compact size
• Low power consumption

Specifications

Transmitter/Receiver

• A/V Transmitting Frequency 2.4GHz
• IR Extender Frequency 433.92MHz
• A/V Signal Range 100 meters (300 feet) clear line of sight
• IR Extender Range 70 meters (200 feet) clear line of sight
• Antenna: Built-in antenna
• Channel: 4 selectable channels
• Audio: Stereo audio input and output
• Video: Composite input and output
• Dimensions: 12.5 x 8 x 2.5 (cm) for transmitter/receiver
• Weight: 125g for transmitter/receiver
• Power: DC6V, 500mA
• Operating Temperature: 32F ~ 104F)

Package Contents

• Transmitter x 1
• Receiver x 1
• Infrared (IR) eye cable x 1
• Remote antenna x 1
• Audio/Video cable x 2
• Power adapters (DC6V) x 2
• User manual x 1

Download Product Manual

Limited Warranty: One Year   Extended Warranty: Available

AITech Part #: 07-000-100-10
